This high-speed automatic vertical laminator machine (JDM-800A) offers speeds up to 60m/min, handling materials up to 780×750mm with 5-15MPa pressure. Ideal for book covers, premium packaging, and advertising materials, it features PLC control and servo motor precision for efficient, professional results.
Engineered to meet the evolving demands of the post-printing packaging industry, our fully automatic high-speed vertical laminating machine delivers exceptional performance for a wide range of applications. With a maximum coating size of 780×750mm and operating speeds ranging from 5-60m/min, this equipment efficiently handles diverse materials including book covers, mid-to-high-end packaging, and advertising displays.
Key features include PLC programmable control with a user-friendly touch interface, servo motor-driven systems for precise operation, and a composite pressure range of 5-15MPa to ensure optimal bonding results. The machine integrates advanced technologies such as electromagnetic heating for uniform temperature distribution, a strong hot air drying system for rapid curing, and a chrome-plated roller gluing system with accuracy within 0.008mm to minimize adhesive waste.
Designed for durability and ease of use, the equipment features a compact structure with high-quality components from international brands. It supports non-terminating paper feeding, automatic powder removal, and finished product collection, enabling full-line automation from feeding to slitting. This cost-effective solution is ideal for large and medium-sized enterprises seeking to enhance production efficiency while maintaining consistent quality standards across their laminated products.
》 High-Speed Performance: Achieves production speeds of 5-60m/min with a maximum processing capacity of 12,000 sheets/hour
》 Precision Engineering: Chrome-plated gluing rollers with <0.008mm accuracy ensure uniform adhesive application and material savings
》 Advanced Heating System: Electromagnetic heating technology provides rapid, uniform temperature distribution for consistent lamination quality
》 Intelligent Automation: PLC control with touch screen interface enables easy operation and real-time parameter adjustment
》 Versatile Applications: Handles materials from 128-500g/m², suitable for book covers, premium packaging, and advertising displays
》 Enhanced Efficiency: Non-terminating paper feeding system reduces downtime and increases overall production capacity
》 Durable Construction: Uses high-quality components from international brands with a robust hydraulic pressure structure
》 User-Centric Design: Features humanized controls, easy film changes, and automatic emergency protection systems for operator safety
| Model | RFM-800A |
| Max. coating size | 780×750mm |
| Min. coating size | 220×260 |
| speed | 5-60 m/min |
| Composite pressure | 5-15 MPa |
| Paper specifications | 128-500g/m² |
| Total power | 45kw |
| Volume (L×W×H) | 6000mm×1750mm×2400mm |
Click to consult and instantly connect with your dedicated printing consultant.
This high-speed laminator runs at 5-60m/min and handles materials up to 780×750mm, perfect for mid-size book covers and packaging.
It uses chrome-plated gluing rollers with accuracy within 0.008mm, ensuring uniform adhesive application and minimizing material waste.
It utilizes electromagnetic heating technology for rapid and uniform temperature distribution, which is key to consistent lamination quality.
Absolutely. It features PLC control with a touch screen interface for easy operation and real-time parameter adjustment.
Key features include non-stop paper feeding, automatic powder removal, and finished product collection for a highly automated production line.
