JDM-1100G Fully Automatic Roll-to-Roll Lamination Machine handles 60-500g/m² paper at 150m/min. Features 200% faster speed, low waste, energy-saving heating, and premium components for stability.
The JDM-1100G Fully Automatic Roll-to-Roll Lamination Machine represents a significant leap forward in post-printing processing technology. Available in three models (RGF-1100, RGF-1550, RGF-1650), it accommodates paper widths from 400mm to 1600mm, making it suitable for diverse production needs across publishing, packaging, and advertising industries. With a maximum speed of 150m/min, this machine achieves a 200% increase in efficiency compared to traditional sheet-fed processes by eliminating manual paper stacking time.
Key technical specifications include support for paper grammage ranging from 60-500g/m² and maximum roll diameter of 1600mm. The machine incorporates advanced electromagnetic heating technology in its heating wheels, reducing heat loss while enabling rapid temperature rise and high energy utilization. Critical electrical components from international brands like RE, Siemens, and Schneider ensure long-term stability and minimize maintenance requirements.
This lamination solution effectively reduces production waste by eliminating sheet-fed cutting excess and thickness-related losses. Its robust construction, with machine weights up to 10,500kg, ensures stable operation even during high-volume production runs. With air pressure requirements of 6bar and power consumption optimized for efficiency, the JDM-1100G delivers consistent, high-quality lamination results for book covers, premium packaging, advertising materials, and documents.
》 200% increased production speed through automated roll-to-roll processing
》 Significant reduction in material waste compared to sheet-fed lamination methods
》 Energy-efficient electromagnetic heating system with rapid temperature response
》 Reliable performance from internationally sourced electrical components
》 Wide processing range accommodating 400-1600mm paper widths
》 Versatile handling of 60-500g/m² paper grammage specifications
》 Robust construction ensuring stable high-volume production
》 Low maintenance design minimizing operational downtime
| Model | RGF-1100 | RGF-1550 | RGF-1650 |
| Maximum Paper Width | 1000mm | 1300mm | 1600mm |
| Minimum Paper Width | 400mm | 400mm | 400mm |
| Maximum Paper Roll Diameter | 1600mm | 1600mm | 1600mm |
| Applicable Paper Grammage | 60-500g/m² | 60-500g/m² | 60-500g/m² |
| Speed | 150m/min | 150m/min | 150m/min |
| Maximum Paper Roll Weight | 1200kg | 1200kg | 1200kg |
| Air Pressure | 6bar | 6bar | 6bar |
| Production Power Consumption | Appro×25kw | Appro×27kw | Appro×30kw |
| Total Power Consumption | Appro×50KW | Appro×52KW | Appro×55KW |
| Machine Dimensions | 8000mm×2930mm×3500mm | 8000mm×3130mm×3500mm | 8000mm×3280mm×3500mm |
| Machine Weight | Appro×9000kg | Appro×9600kg | Appro×10500kg |
Click to consult and instantly connect with your dedicated printing consultant.
Its main advantage is 200% increased production speed through fully automated roll-to-roll processing, eliminating manual sheet handling.
As a roll-to-roll lamination machine, it significantly reduces material waste by avoiding the cutting excess inherent in sheet-fed methods.
It reaches a maximum speed of 150m/min and accommodates paper widths from 400mm to 1600mm across its different models.
It incorporates an energy-efficient electromagnetic heating system in its wheels for rapid temperature response and high energy utilization.
Yes, its robust construction (up to 10,500kg) and international components (e.g., Siemens) ensure stable, high-volume production with low maintenance.
