JDM-1080H fully automatic high-speed vertical laminating machine with hot blade slitting handles water/oil-based adhesives and pre-coated films. Features dual electromagnetic heating, 100m/min speed, 1080×880mm max size.
The JDM-1080H Fully Automatic High-Speed Vertical Laminating Machine (Hot Blade Type) represents the latest innovation in post-press finishing technology. Engineered for versatility, it works seamlessly with water-based adhesives, oil-based adhesives, and pre-coated films, catering to diverse production requirements.
Equipped with a dual electromagnetic heating system combined with hot air circulation, the machine delivers rapid, uniform temperature distribution that accelerates lamination speed while maintaining consistent quality and optimizing energy efficiency. Its advanced hot knife slitting system precisely cuts PET, PVC, BOPP, and metallized films without leaving residual tailings, ensuring clean, professional results.
With a maximum processing size of 1080×880mm and operating speed ranging from 5-100m/min, this high-performance equipment handles paper weights from 128-500g/m² under adjustable composite pressure (5-15 MPa). The PLC-controlled electrical system with touch screen interface enables intuitive operation, while servo motor drives ensure precise positioning throughout the production cycle.
Ideal for book covers, premium packaging, advertising materials, and document finishing, the machine integrates automatic paper feeding, powder removal, gluing, drying, laminating, and collection systems. Key components from international brands ensure reliability and durability, making it a cost-effective solution for large and medium-sized printing enterprises seeking to enhance productivity and product quality.
》 Advanced Heating Technology: Dual electromagnetic heating system with hot air circulation ensures rapid, uniform temperature control for consistent lamination quality
》 Precision Slitting: Industry-leading hot knife system cleanly cuts various film materials without residual tailings
》 High-Speed Performance: Up to 100m/min processing speed with 12,000 sheets/hour paper feeding capacity
》 Versatile Compatibility: Works with water-based adhesives, oil-based adhesives, and pre-coated films
》 Non--terminatingOperation: Continuous paper feeding system minimizes downtime and maximizes productivity
》 Precision Gluing: Chrome-plated rollers with <0.008mm accuracy ensure uniform adhesive application and reduced material waste
》 Intelligent Control: PLC centralized control with touch screen interface enables easy operation and monitoring
》 Premium Components: Internationally renowned brand electrical systems and precision machined parts ensure long-term reliability
| Model | RFM-1080H |
| Max. coating size | 1080×880mm |
| Min. coating size | 280×350 |
| Speed | 5-100m/min |
| Composite pressure | 5-15 MPa |
| Paper specifications | 128-500g/m² |
| Total power | 55kw |
| Volume (L×W×H) | 8500mm×2100mm×2900mm |
| Weight | 8500KG |
Click to consult and instantly connect with your dedicated printing consultant.
It's renowned for its hot blade slitting system that cleanly cuts films like PET/PVC without residue, and its dual electromagnetic heating for fast, uniform temperature control.
This versatile vertical laminator handles water-based, oil-based adhesives, and pre-coated films, making it a true 3-in-1 machine for diverse jobs
It achieves high speeds up to 100m/min, processing a maximum paper size of 1080×880mm, ideal for efficient, large-format production.
PLC control with a touch screen and servo motor drives ensure intuitive operation and precise positioning throughout the lamination cycle.
Yes, it integrates automatic feeding, powder removal, drying, and collection for a continuous workflow, maximizing productivity in high-volume settings.
